Gömülü Bilgisayar Çözümleri

Portwell, özel endüstriyel IoT bilgi işlem ve mobilite çözümlerinin küresel sağlayıcısıdır. Portwell, kapsamlı sistem entegrasyonu, müşteri odaklı tasarım hizmetleri, gömülü sistemler, otomasyon ürünleri ve küresel lojistik desteği sunar.

COM Express Type 6 / 7

Intel®️ Xeon®️ processor D-2100 NT series DIMM DDR4 2667 ECC up to128GB Support 4x USB3.0/2.0, 4x SATA III PCIe Gen 3 expansion (re-arrangeable for different combination of PCIe x16/ x8/ x4/x2/ x1) up to 32 PCIe lanes Support High speed Ethernet (4x XGMII/KR)

Single Board Computer

13th/12th Gen Intel®️ Core™️ processors (Formerly Raptor Lake-S/Alder Lake-S) Dual Channel DDR5 4800 ECC SO-DIMM up to 64GB 16x PCIe Gen 5 and 4x PCIe Gen 4 lanes ready for high speed expansion cards DP and HDMI output on Rear I/O 2x 5GbE, up to 8x USB 3.2 On-board TPM2.0 Paired with Backplane PBPE-08A-A

SOM Module

NXP®️ i.MX 8M Plus Quad-core ARM Cortex-A53 with a Neural Processing Unit (NPU) and Cortex-M7 processor RAM up to 4GB LPDDR4 Up to 32GB on-board eMMC LVDS, HDMI, and MIPI-DSI 4 lanes display option Industrial operating temperature range from -40°C to 85°C Operating system: Linux Yocto, Android

Q-Seven

Intel®️ Atom™️ processor E3900 series, Intel®️ Pentium®️ processor N4200, Intel®️ Celeron®️ processor N3350 Up to 8GB LPDDR4 DRAM eMMC 5.0 up to 64GB (optional) Support extended operating temperature, -40°C to 85°C

ARM donanım ve yazılım araçlarının küresel sağlayıcısı, gömülü uygulamalar için tasarım çözümleri. Geliştirme kartları, tek kartlı bilgisayarlar ve CPU modülleri gibi kart düzeyindeki ürünlerden, değerlendirmenize, prototipinize ve sistem entegrasyonuna veya kendi uygulamalarınızı oluşturmanıza yardımcı olacak çeşitli ürünler.

Single Board Computer

MYS-6ULX (i.MX6UL/6ULL, Cortex-A7) MYS-8MMX (i.MX 8M Mini, Cortex-A53+M4)

CPU Modülleri

MYC-J1028X (LS1028A, Cortex-A72) MYC-JX8MX (i.MX 8M, Cortex-A53+M4) MYC-C8MMX (i.MX 8M Mini, Cortex-A53+M4) MYC-C8MMX-V2 (i.MX 8M Mini, Cortex-A53+M4) MYC-JX8MPQ (i.MX 8M Plus, Cortex-A53+M7) MYC-Y6ULX-V2 (i.MX6UL/6ULL) MYC-IMX28X (i.MX283/287, ARM9)

Development Boards

MYD-J1028X (based on MYC-J1028X) MYD-JX8MX (based on MYC-JX8MX) MYD-C8MMX (based on MYC-C8MMX) MYD-C8MMX-V2 (based on MYC-C8MMX-V2) MYD-JX8MPQ (based on MYC-JX8MPQ) MYD-Y6ULX-V2 (based on MYC-Y6ULX-V2) MYD-Y6ULX-HMI (based on MYC-Y6ULX)

ARBOR, özel endüstriyel IoT bilgi işlem ve mobilite çözümlerinin küresel sağlayıcısıdır. ARBOR, kapsamlı sistem entegrasyonu, müşteri odaklı tasarım hizmetleri, gömülü sistemler, otomasyon ürünleri ve küresel lojistik desteği sunar.

Kompakt CPU Modül

- Soldered onboard 11th Generation Intel® Core™ i7-1185G7E/ i5-1145G7E/ i3-1115G4E/ Celeron 6305E processor
- Intel I219LM PCIe GbE PHY w/ iAMT
- Dual Channels 24-bit LVDS, Analog RGB and 3 x DDI ports
- Support 4 independent displays
- 8.5V~20V Wide Range Voltage Input
- Wide Range Operating Temp.: -40 ~ 85°C

Endüstriyel Anakart

- Ultra Low Profile (16.8mm Height)
- Dual Gigabit Ethernet Ports
- Soldered onboard PenMount Touch Controller
- Dual Independent Dispalys supported
- Additional PCIe x1 Slot for PCI Expansion (need riser card)
- Integrated SIM Socket for mobile telecommunication
- Highly Integrated Communication Interfaces
- Wide Range DC Power Input: 9 ~36V
- Extended Operating Temp.: -20 ~ 70°C

Carrier Board

- Powerful extend Carrier Board for SOM Family
- Multi-Interface to maximize SOM family for variety of applications

System on Board

- Rockchip® RK3399, high-performace ARM 64-bit processor, Dual-Core Cortex A72 +Quad-Core Cortex-A53
- A large form factor of SOM family
- Mali-T860MP4 GPU supports OpenGL ES1.1/2.0/3.0/3.1, OpenVG1.1, OpenCL, DX11
- Various display interfaces for application: eDP, MIPI DSI & HDMI
